533285-4
lmages are for reference only.533285-4
CONN RCPT HD 140POS PCB
Datasheet-
99,551 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
140 Connector Receptacle, Female Sockets Through Hole Brown High Density (HDC, HDI, HPC)
533285-4
| Category | Connectors, Interconnects - Backplane Connectors - Specialized |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | Box II |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Connector Usage | - |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | High Density (HDC, HDI, HPC) |
| Number of Positions | 140 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 4 |
| Number of Columns | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Layout, Typical | - |
| Features | Mating Guide |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Color | Brown |
| Current Rating (Amps) | 3A |
| Material Flammability Rating | - |
| Operating Temperature | -65°C ~ 125°C |
| Voltage Rating | - |
| Base Product Number | 533285 |
| Product Attribute | |
|
|
|
| Part Number | 533285-1 | 533285-2 | 533285-3 | 533285-5 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | CONN RCPT HD 100POS PCB | CONN RCPT HD 120POS PCB | CONN RCPT HD 128POS PCB | CONN RCPT HD 160POS PCB |
| Series | Box II | Box II | Box II | Box II |
| Packaging | Tube | Tube | Bulk | Tube |
