54LS136DMQB
lmages are for reference only.54LS136DMQB
IC GATE XOR 4CH 2-INP 14CERDIP
Datasheet14-CDIP (0.300", 7.62mm)
28,519 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
XOR (Exclusive OR) IC 4 Channel Open Collector 14-CERDIP
54LS136DMQB
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | National Semiconductor |
| Series | 54LS |
| Packaging | Bulk |
| RoHS Status | Not applicable |
| Base Product Number | 54LS136 |
| Logic Type | XOR (Exclusive OR) |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | Open Collector |
| Voltage - Supply | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 10 mA |
| Current - Output High, Low | -, 4mA |
| Input Logic Level - Low | 0.7V |
| Input Logic Level - High | 2V |
| Max Propagation Delay @ V, Max CL | 23ns @ 5V, 15pF |
| Operating Temperature | -55＜C ~ 125＜C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-CERDIP |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 54LS13/BCA | 54ACTQ04E-QMLV | 54ACTQ04W-QMLV | 5962-9758801QCA |
| Manufacturer | Rochester Electronics, LLC | National Semiconductor | National Semiconductor | Texas Instruments |
| RoHS Status | Not applicable | |||
| Description | IC DUAL | IC INVERTER 6CH 1-INP 20LCCC | IC INVERTER 6CH 1-INP 14CFP | IC QUAD 2-INP |
| Series | * | 54ACTQ | 54ACTQ | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
