Optoisolator Transistor with Base Output 5000Vrms 1 Channel 8-DIP
6N135
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | QT Brightek (QTB) |
| Series | Optocoupler |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Current Transfer Ratio (Min) | 7% @ 16mA |
| Current Transfer Ratio (Max) | 50% @ 16mA |
| Turn On / Turn Off Time (Typ) | 350ns, 350ns |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Transistor with Base |
| Voltage - Output (Max) | 20V |
| Current - Output / Channel | 8mA |
| Voltage - Forward (Vf) (Typ) | 1.45V |
| Current - DC Forward (If) (Max) | 25 mA |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-DIP |
| Base Product Number | 6N135 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | 6N135 | 6N135 | 6N135 | 6N135 |
| Manufacturer | onsemi | Broadcom Limited | Fairchild Semiconductor | Everlight Electronics Co Ltd |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | OPTOISO 2.5KV TRANS W/BASE 8DIP | OPTOISO 3.75KV TRANS W/BASE 8DIP | LOGIC IC OUTPUT OPTOCOUPLER | OPTOISO 5KV TRANS W/BASE 8DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
