744750340047
lmages are for reference only.744750340047
FIXED IND 4.7UH 9A 8.5 MOHM TH
DatasheetRadial, Vertical Cylinder
59,383 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
4.7 µH Shielded Drum Core, Wirewound Inductor 9 A 8.5mOhm Max Radial, Vertical Cylinder
744750340047
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Würth Elektronik |
| Series | WE-FAMI |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 4.7 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 9 A |
| Current - Saturation (Isat) | 14.4A |
| Shielding | Shielded |
| DC Resistance (DCR) | 8.5mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.425" Dia (10.80mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | 744750340150 | 744750230068 | 744750230150 | 744750420047 |
| Manufacturer | Würth Elektronik | Würth Elektronik | Würth Elektronik | Würth Elektronik |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 15UH 5.6A 20 MOHM TH | FIXED IND 6.8UH 5.7A 16 MOHM TH | FIXED IND 15UH 3.7A 35 MOHM TH | FIXED IND 4.7UH 8.7A 8.5MOHM TH |
| Series | Würth Elektronik | Würth Elektronik | Würth Elektronik | Würth Elektronik |
| Packaging | Tray | Tray | Tray | Tray |
