74VCX86BQX
lmages are for reference only.74VCX86BQX
IC GATE XOR 4CH 2-INP 14DQFN
Datasheet14-VFQFN Exposed Pad
37,684 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
XOR (Exclusive OR) IC 4 Channel 14-DQFN (3x2.5)
74VCX86BQX
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Fairchild Semiconductor |
| Series | 74VCX |
| Packaging | Bulk |
| RoHS Status | |
| Base Product Number | 74VCX86 |
| Logic Type | XOR (Exclusive OR) |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 1.2V ~ 3.6V |
| Current - Quiescent (Max) | 20 µA |
| Current - Output High, Low | 24mA, 24mA |
| Input Logic Level - Low | 0.7V ~ 0.8V |
| Input Logic Level - High | 1.6V ~ 2V |
| Max Propagation Delay @ V, Max CL | 3ns @ 3.3V, 30pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-DQFN (3x2.5) |
| Package / Case | 14-VFQFN Exposed Pad |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | 74VCX86BQX | 74VCX86M | 74VCX86M | 74VCX86MTC |
| Manufacturer | onsemi | onsemi | Fairchild Semiconductor | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC GATE XOR 4CH 2-INP 14DQFN | IC GATE XOR 4CH 2-INP 14SOIC | IC GATE XOR 4CH 2-INP 14SOIC | IC GATE XOR 4CH 2-INP 14TSSOP |
| Series | 74VCX | 74VCX | 74VCX | 74VCX |
| Packaging | Tape & Reel (TR) | Tube | Tube | Tube |
