803-93-054-10-004000
Manufacturer
Mill-Max Manufacturing Corp.Description
STANDARD SOCKET HEADER
Datasheet
DatasheetPackage
-
In Stock
60,504 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
803-93-054-10-004000
803-93-054-10-004000
lmages are for reference only.Payment Methods
Delivery Services
54 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold
Quick Inquiry
803-93-054-10-004000
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Receptacles-Female Sockets |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 803 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Style | Board to Board |
| Number of Positions | 54 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Termination | Solder Cup |
| Fastening Type | Push-Pull |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Insulation Color | Black |
| Insulation Height | 0.110" (2.79mm) |
| Contact Length - Post | 0.340" (8.64mm) |
| Operating Temperature | -55°C ~ 125°C |
| Material Flammability Rating | - |
| Contact Finish - Post | Gold |
| Mated Stacking Heights | - |
| Ingress Protection | - |
| Features | - |
| Current Rating (Amps) | 3A |
| Voltage Rating | 100VAC, 150VDC |
| Applications | - |
| Insulation Material | Thermoplastic |
| Contact Shape | Circular |
| Contact Material | Brass Alloy |
| Contact Finish Thickness - Post | 10.0µin (0.25µm) |
| Base Product Number | - |
