80MXC5600MEFCSN30X45
lmages are for reference only.Payment Methods
Delivery Services
5600 µF 80 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 3000 Hrs @ 105°C
80MXC5600MEFCSN30X45
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Rubycon |
| Series | MXC |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 5600 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.8 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.37 A @ 10 kHz |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.850" (47.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Base Product Number | - |
| Impedance | - |
| Product Attribute | |
 |
|
 |
| Part Number | 80MXC5600MEFCSN30X45 | 80MXC5600MEFCSN35X40 | 80MXC5600MEFCSN35X40 | 80MXC5600MEFC30X45 |
| Manufacturer | Rubycon | Rubycon | Rubycon | Rubycon |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | CAP ALUM 5600UF 20% 80V SNAP TH | CAP ALUM 5600UF 20% 80V SNAP TH | CAP ALUM 5600UF 20% 80V SNAP TH | CAP ALUM 5600UF 20% 80V SNAP TH |
| Series | Rubycon | Rubycon | Rubycon | Rubycon |
| Packaging | Bulk | Bulk | Bulk | Bulk |
