Product CatalogPart Number
81028032A
Manufacturer
Broadcom LimitedDescription
OPTOISO 1.5KV 2CH OPN COL 20LCCC
Datasheet
DatasheetPackage
20-CLCC
In Stock
44,786 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
81028032A
81028032A
lmages are for reference only.Payment Methods
Delivery Services
Logic Output Optoisolator 10MBd Open Collector, Schottky Clamped 1500VDC 2 Channel 1kV/µs CMTI 20-LCCC (8.89x8.89)
Quick Inquiry
81028032A
Specifications
| Category | Isolators - Optoisolators - Logic Output Optoisolators |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Number of Channels | 2 |
| Inputs - Side 1/Side 2 | 2/0 |
| Voltage - Isolation | 1500VDC |
| Common Mode Transient Immunity (Min) | 1kV/µs |
| Input Type | DC |
| Output Type | Open Collector, Schottky Clamped |
| Current - Output / Channel | 25 mA |
| Data Rate | 10MBd |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Rise / Fall Time (Typ) | 35ns, 35ns |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Current - DC Forward (If) (Max) | 20mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-CLCC |
| Supplier Device Package | 20-LCCC (8.89x8.89) |
| Base Product Number | 8102803 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute | |
 |
|
 |
| Part Number | 81028032A | 8102801EA | 8102801EA | 8102801EC |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | OPTOISO 1.5KV 2CH OPN COL 20LCCC | OPTOISO 1.5KV 2CH OPEN COL 16DIP | OPTOISO 1.5KV 2CH OPEN COL 16DIP | OPTOISO 1.5KV 2CH OPEN COL 16DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
