CONN SOCKET PLCC 20POS TIN-LEAD
Datasheet-
26,425 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
20 (4 x 5) Pos PLCC Socket Tin-Lead Through Hole
940-99-020-24-000000
| Category | Connectors, Interconnects - Sockets for ICs-Transistors - IC Sockets |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 940 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | PLCC |
| Number of Positions or Pins (Grid) | 20 (4 x 5) |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Finish - Mating | Tin-Lead |
| Contact Finish Thickness - Mating | 100.0µin (2.54µm) |
| Contact Material - Mating | Beryllium Copper |
| Mounting Type | Through Hole |
| Features | Closed Frame |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Contact Finish - Post | Tin-Lead |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Material - Post | Brass Alloy |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester |
| Operating Temperature | -55°C ~ 125°C |
| Termination Post Length | 0.130" (3.30mm) |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 1 A |
| Contact Resistance | 30mOhm |
| Base Product Number | 940-99 |
| Product Attribute |  |
 |
 |
 |
| Part Number | 940-99-020-17-400000 | 940-99-028-17-400000 | 940-99-028-24-000000 | 940-99-032-17-400000 |
| Manufacturer | Mill-Max Manufacturing Corp. | Mill-Max Manufacturing Corp. | Mill-Max Manufacturing Corp. | Mill-Max Manufacturing Corp. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CONN SOCKET PLCC 20POS TIN-LEAD | CONN SOCKET PLCC 28POS TIN-LEAD | CONN SOCKET PLCC 28POS TIN-LEAD | CONN SOCKET PLCC 32POS TIN-LEAD |
| Series | 940 | 940 | 940 | 940 |
| Packaging | Tube | Tube | Tube | Tube |
