Product CatalogPart Number
A-32-04H-130L
Manufacturer
Assmann WSW ComponentsDescription
MICROMINIATURE
Datasheet
DatasheetPackage
-
In Stock
72,679 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
A-32-04H-130L
A-32-04H-130L
lmages are for reference only.Payment Methods
Delivery Services
4 Position Header Connector Red IDC Through Hole, Right Angle, Press-Fit
Quick Inquiry
A-32-04H-130L
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Board In-Direct Wire to Board |
| Manufacturer | Assmann WSW Components |
| Series | Micro-Minature |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header |
| Number of Positions | 4 |
| Cable Pitch | 0.100" (2.54mm) |
| Board-Side Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Mounting Type | Through Hole, Right Angle, Press-Fit |
| Cable Termination | IDC |
| Wire Gauge | - |
| Features | - |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Red |
| Number of Positions Loaded | All |
| Base Product Number | A-32-04H |
Parts with Similar Specifications
| Product Attribute |  |
|
|
|
| Part Number | A-32-04H-1300 | A-30-04P-1300 | A-30-06P-1300 | A-30-08P-1300 |
| Manufacturer | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MICROMINIATURE, FEMALE, 1.27MM, | MICROMINIATURE | MICROMINIATURE | MICROMINIATURE |
| Series | Micro-Minature | Micro-Minature | Micro-Minature | Micro-Minature |
| Packaging | Tube | Bulk | Bulk | Bulk |
