Product CatalogPart Number
A-WBP-K002DA-20TB02
Manufacturer
Assmann WSW ComponentsDescription
WIRE-TO-BOARD, WAFER, 2.00MM, 20
Datasheet
DatasheetPackage
-
In Stock
47,492 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
A-WBP-K002DA-20TB02
A-WBP-K002DA-20TB02
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Through Hole, Right Angle 20 position 0.079" (2.00mm)
Quick Inquiry
A-WBP-K002DA-20TB02
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Assmann WSW Components |
| Series | A-WBP |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch - Mating | 0.079" (2.00mm) |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.079" (2.00mm) |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Detent Lock |
| Contact Length - Mating | - |
| Contact Length - Post | 0.118" (3.00mm) |
| Overall Contact Length | - |
| Insulation Height | 0.197" (5.00mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | Flash |
| Contact Finish - Post | - |
| Contact Material | Brass |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Features | Keying Slot |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | Gray |
| Current Rating (Amps) | 3A |
| Voltage Rating | 250VAC/DC |
| Mated Stacking Heights | - |
| Contact Finish Thickness - Post | - |
| Applications | - |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | A-WBP-K002DA-20TB01 | A-WBP-K002DA-04TB01 | A-WBP-K002DA-04TB02 | A-WBP-K002DA-06TB01 |
| Manufacturer | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | WIRE-TO-BOARD, WAFER, 2.00MM, 20 | WIRE-TO-BOARD, WAFER, 2.00MM, 4P | WIRE-TO-BOARD, WAFER, 2.00MM, 4P | WIRE-TO-BOARD, WAFER, 2.00MM, 6P |
| Series | A-WBP | A-WBP | A-WBP | A-WBP |
| Packaging | Bag | Bag | Bag | Bag |
