Product CatalogPart Number
A-WBP-L005EG-02TB02
Manufacturer
Assmann WSW ComponentsDescription
WIRE-TO-BOARD, WAFER, 2.50MM, 2P
Datasheet
DatasheetPackage
-
In Stock
48,363 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
A-WBP-L005EG-02TB02
A-WBP-L005EG-02TB02
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Through Hole 2 position 0.098" (2.50mm)
Quick Inquiry
A-WBP-L005EG-02TB02
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Assmann WSW Components |
| Series | A-WBP |
| Packaging | Bag |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Header |
| Contact Type | Male Pin |
| Pitch - Mating | 0.098" (2.50mm) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Row Spacing - Mating | - |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Through Hole |
| Termination | Kinked Pin, Solder |
| Fastening Type | Locking Ramp |
| Contact Length - Mating | - |
| Contact Length - Post | 0.134" (3.40mm) |
| Overall Contact Length | - |
| Insulation Height | 0.280" (7.10mm) |
| Contact Shape | Square |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin |
| Contact Material | Brass |
| Insulation Material | Polyamide (PA66), Nylon 6/6 |
| Features | - |
| Operating Temperature | -40°C ~ 105°C |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Insulation Color | White |
| Current Rating (Amps) | 3A |
| Voltage Rating | 500VAC/DC |
| Mated Stacking Heights | - |
| Contact Finish Thickness - Post | - |
| Applications | - |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute | |
 |
|
 |
| Part Number | A-WBP-L005EG-02TB01 | A-WBP-L005EG-03TB01 | A-WBP-L005EG-03TB02 | A-WBP-L005EG-04TB01 |
| Manufacturer | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components | Assmann WSW Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | WIRE-TO-BOARD, WAFER, 2.50MM, 2P | WIRE-TO-BOARD, WAFER, 2.50MM, 3P | WIRE-TO-BOARD, WAFER, 2.50MM, 3P | WIRE-TO-BOARD, WAFER, 2.50MM, 4P |
| Series | A-WBP | A-WBP | A-WBP | A-WBP |
| Packaging | Bag | Bag | Bag | Bag |
