AD7949BCPZ
lmages are for reference only.AD7949BCPZ
IC ADC 14BIT SAR 20LFCSP
Datasheet20-WFQFN Exposed Pad, CSP
99,661 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
14 Bit Analog to Digital Converter 8 Input 1 SAR 20-LFCSP (4x4)
AD7949BCPZ
| Category | Integrated Circuits (ICs) - Data Acquisition - Analog to Digital Converters ADC |
| Manufacturer | Analog Devices Inc. |
| Series | PulSAR® |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 250k |
| Number of Inputs | 8 |
| Input Type | Differential, Pseudo-Differential, Single Ended |
| Data Interface | SPI, DSP |
| Configuration | MUX-S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 2.3V ~ 5.5V |
| Voltage - Supply, Digital | 2.3V ~ 5.5V |
| Features | Temperature Sensor |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 20-WFQFN Exposed Pad, CSP |
| Supplier Device Package | 20-LFCSP (4x4) |
| Mounting Type | Surface Mount |
| Base Product Number | AD7949 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AD7949BCPZRL7 | AD7902BRQZ | AD7902BRQZ-RL7 | AD7903BRQZ |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC ADC 14BIT SAR 20LFCSP | IC ADC 16BIT SAR 20QSOP | IC ADC 16BIT SAR 20QSOP | IC ADC 16BIT SAR 20QSOP |
| Series | PulSAR® | PulSAR® | PulSAR® | PulSAR® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
