ADG452BR
lmages are for reference only.ADG452BR
IC SWITCH SPST-NOX4 5OHM 16SOIC
Datasheet16-SOIC (0.154", 3.90mm Width)
49,253 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
4 Circuit IC Switch 1:1 5Ohm 16-SOIC
ADG452BR
| Category | Integrated Circuits (ICs) - Interface - Analog Switches-Multiplexers-Demultiplexers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 5Ohm |
| Channel-to-Channel Matching (ΔRon) | 100mOhm |
| Voltage - Supply, Single (V+) | 12V |
| Voltage - Supply, Dual (V±) | ±4.5V ~ 20V |
| Switch Time (Ton, Toff) (Max) | 180ns, 140ns |
| -3db Bandwidth | - |
| Charge Injection | 20pC |
| Channel Capacitance (CS(off), CD(off)) | 37pF, 37pF |
| Current - Leakage (IS(off)) (Max) | 500pA |
| Crosstalk | -90dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | ADG452 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
|
| Part Number | ADG452BN | ADG452BN | ADG452BNZ | ADG452BNZ |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC SWITCH SPST-NO X 4 5OHM 16DIP | IC SWITCH SPST-NO X 4 5OHM 16DIP | IC SWITCH SPST-NO X 4 5OHM 16DIP | IC SWITCH SPST-NO X 4 5OHM 16DIP |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
