ADP2120ACPZ-1.8-R7
lmages are for reference only.ADP2120ACPZ-1.8-R7
IC REG BUCK 1.8V 1.25A 10LFCSP
Datasheet10-VFDFN Exposed Pad, CSP
94,713 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck Switching Regulator IC Positive Fixed 1.8V 1 Output 1.25A 10-VFDFN Exposed Pad, CSP
ADP2120ACPZ-1.8-R7
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 2.3V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1.8V |
| Voltage - Output (Max) | - |
| Current - Output | 1.25A |
| Frequency - Switching | 1.2MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 10-VFDFN Exposed Pad, CSP |
| Supplier Device Package | 10-LFCSP-WD (3x3) |
| Base Product Number | ADP2120 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADP2120ACPZ-1.0-R7 | ADP2120ACPZ-1.2-R7 | ADP2120ACPZ-1.5-R7 | ADP2120ACPZ-2.5-R7 |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK 1V 1.25A 10LFCSP | IC REG BUCK 1.2V 1.25A 10LFCSP | IC REG BUCK 1.5V 1.25A 10LFCSP | IC REG BUCK 2.5V 1.25A 10LFCSP |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
