ADP5076ACBZ-R7
lmages are for reference only.ADP5076ACBZ-R7
IC REG BOOST ADJ DL 20WLCSP
Datasheet20-UFBGA, WLCSP
51,276 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Boost Switching Regulator IC Positive and Negative Adjustable 0.8V 2 Output 2A (Switch), 1.2A (Switch) 20-UFBGA, WLCSP
ADP5076ACBZ-R7
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Function | Step-Up |
| Output Configuration | Positive and Negative |
| Topology | Boost |
| Output Type | Adjustable |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 2.85V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 35V, -30V |
| Current - Output | 2A (Switch), 1.2A (Switch) |
| Frequency - Switching | 1.2MHz, 2.4MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 20-UFBGA, WLCSP |
| Supplier Device Package | 20-WLCSP (1.61x2.18) |
| Base Product Number | ADP5076 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADP5014ACPZ-R7 | ADP5053ACPZ-R7 | ADP5055ACCZ-R7 | ADP5056ACCZ-R7 |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG BUCK PROG QUAD 40LFCSP | IC REG BUCK ADJ QUAD 48LFCSP | IC REG BUCK ADJ TRPL 43LGA | IC REG BUCK ADJ TRPL 43LGA |
| Series | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
