Product CatalogPart Number
ADT005-10E
Manufacturer
NVE Corp/Isolation ProductsDescription
Linear IC's
Datasheet
DatasheetPackage
6-WDFN Exposed Pad
In Stock
71,641 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ADT005-10E
ADT005-10E
lmages are for reference only.Payment Methods
Delivery Services
Magnetoresistive Sensor Rotary Position External Magnet, Not Included SMD (SMT) Tab
Quick Inquiry
ADT005-10E
Specifications
| Category | Sensors, Transducers - Position Sensors - Angle-Linear Position Measuring |
| Manufacturer | NVE Corp/Isolation Products |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| For Measuring | Rotary Position |
| Technology | Magnetoresistive |
| Rotation Angle - Electrical, Mechanical | 0° ~ 360°, Continuous |
| Linear Range | - |
| Output | Wheatstone Bridge |
| Output Signal | Cosine, Sine |
| Actuator Type | External Magnet, Not Included |
| Linearity | - |
| Resistance | - |
| Resistance Tolerance | - |
| Voltage - Supply | 2.4V ~ 5.5V |
| Mounting Type | Surface Mount |
| Termination Style | SMD (SMT) Tab |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 6-WDFN Exposed Pad |
| Supplier Device Package | 6-TDFN (2.5x2.5) |
| Grade | - |
| Qualification | - |
| Base Product Number | - |
