ADUM241E1BRIZ-RL
lmages are for reference only.ADUM241E1BRIZ-RL
DGTL ISO 5000VRMS 4CH GP 16SOIC
Datasheet16-SOIC (0.295", 7.50mm Width)
74,588 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 75kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
ADUM241E1BRIZ-RL
| Category | Isolators - Digital Isolators - |
| Manufacturer | Analog Devices Inc. |
| Series | iCoupler® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | Magnetic Coupling |
| Type | General Purpose |
| Isolated Power | No |
| Number of Channels | 4 |
| Inputs - Side 1/Side 2 | 3/1 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 75kV/µs |
| Data Rate | 150Mbps |
| Propagation Delay tpLH / tpHL (Max) | 13ns, 13ns |
| Pulse Width Distortion (Max) | 3ns |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Voltage - Supply | 1.7V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Base Product Number | ADUM241 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADUM241E1BRIZ | ADUM241E1BRWZ | ADUM241E1BRWZ-RL | ADUM2400ARIZ |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGTL ISO 5000VRMS 4CH GP 16SOIC | DGTL ISO 5000VRMS 4CH GP 16SOIC | DGTL ISO 5000VRMS 4CH GP 16SOIC | DGTL ISO 5000VRMS 4CH GP 16SOIC |
| Series | iCoupler® | iCoupler® | iCoupler® | iCoupler® |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
