SPI Digital Isolator 3750Vrms 7 Channel 34Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
ADUM3153BRSZ
| Category | Isolators - Digital Isolators - |
| Manufacturer | Analog Devices Inc. |
| Series | iCoupler®, SPIsolator™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Technology | Magnetic Coupling |
| Type | SPI |
| Isolated Power | No |
| Number of Channels | 7 |
| Inputs - Side 1/Side 2 | 3/4 |
| Channel Type | Unidirectional |
| Voltage - Isolation | 3750Vrms |
| Common Mode Transient Immunity (Min) | 25kV/µs |
| Data Rate | 34Mbps |
| Propagation Delay tpLH / tpHL (Max) | 14ns, 14ns |
| Pulse Width Distortion (Max) | 2ns |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Voltage - Supply | 3V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 20-SSOP |
| Base Product Number | ADUM3153 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ADUM3153BRSZ-RL7 | ADUM3100ARZ | ADUM3100ARZ-RL7 | ADUM3100BRZ |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGT ISOL 3750VRMS 7CH SPI 20SSOP | DGTL ISO 2500VRMS 1CH GP 8SOIC | DGTL ISO 2500VRMS 1CH GP 8SOIC | DGTL ISO 2500VRMS 1CH GP 8SOIC |
| Series | iCoupler®, SPIsolator™ | iCoupler® | iCoupler® | iCoupler® |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
