AE10000B10625
lmages are for reference only.AE10000B10625
RF FILTER BAND PASS 10GHZ MODULE
DatasheetModule, SMA Connectors
29,159 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
10GHz Center Frequency Band Pass RF Filter (Radio Frequency) 200MHz Bandwidth 1.7dB Module, SMA Connectors
AE10000B10625
| Category | Filters - RF Filters - |
| Manufacturer | Anatech Electronics Inc. |
| Series | - |
| Packaging | Box |
| RoHS Status | Not applicable |
| Frequency | 10GHz Center |
| Bandwidth | 200MHz |
| Filter Type | Band Pass |
| Ripple | - |
| Insertion Loss | 1.7dB |
| Mounting Type | Chassis Mount |
| Package / Case | Module, SMA Connectors |
| Size / Dimension | 0.400" L x 1.500" W (10.16mm x 38.10mm) |
| Height (Max) | 0.750" (19.05mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
|
|
| Part Number | AE10000SLB1005 | AE10000SSH6566 | AE1.25B10710 | AE1.2L8836 |
| Manufacturer | Anatech Electronics Inc. | Anatech Electronics Inc. | Anatech Electronics Inc. | Anatech Electronics Inc. |
| RoHS Status | Not applicable | Not applicable | Not applicable | Not applicable |
| Description | RF FILTER BAND PASS 10GHZ MODULE | RF FILTER HIGH PASS 10GHZ MODULE | RF FILTER BAND PASS 1.25MHZ BNC | RF FILTER LOW PASS 1.2MHZ BNC |
| Series | - | - | - | - |
| Packaging | Box | Box | Box | Box |
