AEE02CC12-M
Manufacturer
ARTESYN / Advanced EnergyDescription
DC DC CONVERTER +/-15V 20W
Datasheet
DatasheetPackage
5-DIP Module
In Stock
12,830 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AEE02CC12-M
AEE02CC12-M
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 2 Output 15V -15V 670mA, 670mA 9V - 18V Input
Quick Inquiry
AEE02CC12-M
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | ARTESYN / Advanced Energy |
| Series | AEE20W-M (20W) |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Type | Isolated Module |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 9V |
| Voltage - Input (Max) | 18V |
| Voltage - Output 1 | 15V |
| Voltage - Output 2 | -15V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 670mA, 670mA |
| Power (Watts) | 20 W |
| Applications | ITE (Commercial), Medical |
| Features | OCP, OVP, SCP |
| Operating Temperature | -40°C ~ 80°C (With Derating) |
| Efficiency | 89% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 5-DIP Module |
| Size / Dimension | 2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 12.0mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | AEE02CC |
| Voltage - Isolation | 4.2 kV |
