AGN260A1HW
Manufacturer
Panasonic Electric WorksDescription
RELAY GEN PURPOSE DPDT 1A 1.5V
Datasheet
DatasheetPackage
-
In Stock
95,721 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AGN260A1HW
AGN260A1HW
lmages are for reference only.Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) Surface Mount
Quick Inquiry
AGN260A1HW
Specifications
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | Panasonic Electric Works |
| Series | AGN |
| Packaging | Bulk |
| RoHS Status | |
| Mounting Type | Surface Mount |
| Coil Voltage | 1.5VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 125VAC, 110VDC - Max |
| Load - Max Switching | 125VA, 110W |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Gull Wing |
| Seal Rating | Sealed - Fully |
| Coil Insulation | - |
| Must Operate Voltage | 1.2 VDC |
| Must Release Voltage | 0.15 VDC |
| Operate Time | 4 ms |
| Release Time | 4 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Approval Agency | BSI, cURus |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | AGN260 |
| Coil Current | 66.7 mA |
| Coil Resistance | 22.5 Ohms |
