AH3320Q-SA-7
lmages are for reference only.AH3320Q-SA-7
HALL UNIPOLAR SWITCH SSOT23 T&R
DatasheetTO-236-3, SC-59, SOT-23-3
97,423 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Digital Switch Unipolar Switch Open Drain Hall Effect SOT-23-3
AH3320Q-SA-7
| Category | Sensors, Transducers - Magnetic Sensors - Switches Solid State |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Function | Unipolar Switch |
| Technology | Hall Effect |
| Polarization | - |
| Sensing Range | 24mT Trip, 15.5mT Release |
| Test Condition | -40°C ~ 150°C |
| Voltage - Supply | 3V ~ 28V |
| Current - Supply (Max) | 3mA |
| Current - Output (Max) | 30mA |
| Output Type | Open Drain |
| Features | - |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-3 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AH1381-FS4-7 | AH1381-HK4-7 | AH1381-SA-7 | AH1382-FS4-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | HALL UNIPOLAR SWITCH X2-DFN1010- | HALL UNIPOLAR SWITCH X2-DFN1410 | HALL UNIPOLAR SWITCH SSOT23 T&R | HALL UNIPOLAR SWITCH X2-DFN1010- |
| Series | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
