AISC-1210H-270K-T
lmages are for reference only.AISC-1210H-270K-T
FIXED IND 27UH 380MA 1.24OHM SMD
Datasheet1210 (3225 Metric)
99,236 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
27 µH Unshielded Drum Core, Wirewound Inductor 380 mA 1.24Ohm Max 1210 (3225 Metric)
AISC-1210H-270K-T
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Abracon LLC |
| Series | AISC-1210H |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 27 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 380 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 1.24Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 18MHz |
| Ratings | - |
| Operating Temperature | -25°C ~ 85°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) |
| Supplier Device Package | 1210 |
| Size / Dimension | 0.138" L x 0.098" W (3.50mm x 2.50mm) |
| Height - Seated (Max) | 0.098" (2.50mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
|
| Part Number | AISC-1210H-120K-T | AISC-1210H-121K-T | AISC-1210H-150K-T | AISC-1210H-150K-T |
| Manufacturer | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 12UH 610MA 674MOHM SMD | FIXED IND 120UH 160MA 7.47OHM SM | FIXED IND 15UH 550MA 760MOHM SMD | FIXED IND 15UH 550MA 760MOHM SMD |
| Series | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
