ALH156K401C084
lmages are for reference only.ALH156K401C084
CAP FILM 15UF 400VAC RAD 4 LEAD
DatasheetRadial - 4 Leads
39,544 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
15 µF Film Capacitor 400V Polypropylene (PP) Radial - 4 Leads
ALH156K401C084
| Category | Capacitors - Film Capacitors - |
| Manufacturer | Cornell Dubilier Knowles |
| Series | ALH |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 15 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | 400V |
| Voltage Rating - DC | - |
| Dielectric Material | Polypropylene (PP) |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial - 4 Leads |
| Size / Dimension | 2.264" L x 1.378" W (57.50mm x 35.00mm) |
| Height - Seated (Max) | 2.008" (51.00mm) |
| Termination | PC Pins |
| Lead Spacing | 2.067" (52.50mm) |
| Applications | Automotive; EMI, RFI Suppression |
| Ratings | AEC-Q200 |
| Features | 85C/85% Humidity, THB, Low ESR, Low ESL, Long Life |
| ESR (Equivalent Series Resistance) | 6.1 mOhms |
| Base Product Number | ALH |
| Product Attribute |  |
 |
 |
 |
| Part Number | ALH105K161A022 | ALH105K251A022 | ALH105K271A022 | ALH105K351A032 |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 1UF 10% 160VAC RADIAL | CAP FILM 1UF 10% 250VAC RADIAL | CAP FILM 1UF 10% 275VAC RADIAL | CAP FILM 1UF 10% 350VAC RADIAL |
| Series | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| Packaging | Bulk | Bulk | Bulk | Bulk |
