AM23ESGC
Manufacturer
KingbrightDescription
LED GREEN/RED CLEAR SOT23-3 SMD
Datasheet
DatasheetPackage
TO-236-3, SC-59, SOT-23-3
In Stock
65,626 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AM23ESGC
AM23ESGC
lmages are for reference only.Payment Methods
Delivery Services
Green, Red 568nm Green, 617nm Red LED Indication - Discrete 2.2V Green, 2V Red TO-236-3, SC-59, SOT-23-3
Quick Inquiry
AM23ESGC
Specifications
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Kingbright |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Green, Red |
| Configuration | Common Cathode |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 10mcd Green, 5mcd Red |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 3.00mm x 1.30mm |
| Voltage - Forward (Vf) (Typ) | 2.2V Green, 2V Red |
| Current - Test | 20mA Green, 20mA Red |
| Viewing Angle | 140° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 568nm Green, 617nm Red |
| Wavelength - Peak | 565nm Green, 627nm Red |
| Features | - |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| Size / Dimension | 3.00mm L x 1.30mm W |
| Height (Max) | 1.20mm |
| Base Product Number | AM23 |
| Grade | - |
| Qualification | - |
