Product CatalogPart Number
AMSR2-783.3JZ
Manufacturer
aimtecDescription
DC DC CONVERTER 3.3V 6.6W
Datasheet
DatasheetPackage
3-SIP Module
In Stock
87,483 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AMSR2-783.3JZ
AMSR2-783.3JZ
lmages are for reference only.Payment Methods
Delivery Services
Non-Isolated PoL Module DC DC Converter 1 Output 3.3V 2A 6V - 36V Input
Quick Inquiry
AMSR2-783.3JZ
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | aimtec |
| Series | AMSR2-78JZ (2W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 6V |
| Voltage - Input (Max) | 36V |
| Voltage - Output 1 | 3.3V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 2A |
| Power (Watts) | 6.6 W |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 83% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 3-SIP Module |
| Size / Dimension | 0.45" L x 0.35" W x 0.69" H (11.5mm x 8.9mm x 17.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | AMSR2 |
| Voltage - Isolation | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | AMSR2-783.3LJZ | AMSR2-7805JZ | AMSR2-7809JZ | AMSR2-7812JZ |
| Manufacturer | aimtec | aimtec | aimtec | aimtec |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 6.6W 3.3V DC/DC CONVERTER | DC DC CONVERTER 5V 10W | DC DC CONVERTER 9V 18W | DC DC CONVERTER 12V 24W |
| Series | aimtec | aimtec | aimtec | aimtec |
| Packaging | Tube | Tube | Tube | Tube |
