AO3420L
lmages are for reference only.AO3420L
MOSFET N-CHANNEL 20V 6A SOT23-3
Datasheet3-SMD, SOT-23-3 Variant
46,379 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 20 V 6A (Ta) 1.4W (Ta) Surface Mount SOT-23-3
AO3420L
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Alpha & Omega Semiconductor Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 6A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 10V |
| Rds On (Max) @ Id, Vgs | 24mOhm @ 6A, 10V |
| Vgs(th) (Max) @ Id | 1.1V @ 250µA |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 630 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.4W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-23-3 |
| Package / Case | 3-SMD, SOT-23-3 Variant |
| Base Product Number | AO34 |
| Gate Charge (Qg) (Max) @ Vgs | 12.5 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AO3420 | AO3400 | AO3400-5.8A | AO3400A |
| Manufacturer | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | MDD | Alpha & Omega Semiconductor Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 20V 6A SOT23-3L | MOSFET N-CH 30V 5.8A SOT23-3 | MOSFET SOT-23 N Channel 30V | MOSFET N-CH 30V 5.7A SOT23-3L |
| Series | - | - | SOT-23 | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
