AOCA33103E
lmages are for reference only.AOCA33103E
MOSFET 2N-CH 12V 40A 10DFN
Datasheet10-SMD, No Lead
41,123 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 12V 40A (Ta) 3.1W (Ta) Surface Mount 10-AlphaDFN (2.52x2.52)
AOCA33103E
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Alpha & Omega Semiconductor Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) Common Drain |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 12V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Ta) |
| Rds On (Max) @ Id, Vgs | 1.8mOhm @ 5A, 4.5V |
| Vgs(th) (Max) @ Id | 1.3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 45nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | - |
| Power - Max | 3.1W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD, No Lead |
| Supplier Device Package | 10-AlphaDFN (2.52x2.52) |
| Base Product Number | AOCA33103 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | AOCA33102E | AOCA33104A | AOCA33104E | AOCA24106C |
| Manufacturer | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | MOSFET 2N-CH 12V 50A 14DFN | MOSFET 2N-CH 12V 30A 10DFN | MOSFET 2N-CH 12V 30A 10DFN | MOSFET 2N-CH 12V 20A 6DFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
