AP2111H-1.2TRG1

AP2111H-1.2TRG1

AP2111H-1.2TRG1

lmages are for reference only.
  • Part Number

    AP2111H-1.2TRG1

  • Manufacturer

    Diodes Incorporated
  • Description

    IC REG LINEAR 1.2V 600MA SOT223

  • Datasheet

    DatasheetDatasheet
  • Package

    TO-261-4, TO-261AA

  • In Stock

    41,791 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

Linear Voltage Regulator IC Positive Fixed 1 Output 600mA SOT-223-3

Quick Inquiry

AP2111H-1.2TRG1

Get the Price Now!

Specifications

Category Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators
Manufacturer Diodes Incorporated
Series -
Packaging Tape & Reel (TR)
RoHS Status ROHS3 Compliant
Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 6V
Voltage - Output (Min/Fixed) 1.2V
Voltage - Output (Max) -
Voltage Dropout (Max) 0.3V @ 600mA
Current - Output 600mA
Current - Quiescent (Iq) 80 µA
PSRR 65dB (100Hz ~ 1kHz)
Control Features -
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Operating Temperature -40°C ~ 85°C
Grade -
Qualification -
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Supplier Device Package SOT-223-3
Base Product Number AP2111
Current - Supply (Max) -

Parts with Similar Specifications

Product Attribute AP2111H-1.8TRG1 AP2111H-2.5TRG1 AP2111H-3.3TRG1 AP2111H-4.8TRG1
Part Number AP2111H-1.8TRG1 AP2111H-2.5TRG1 AP2111H-3.3TRG1 AP2111H-4.8TRG1
Manufacturer Diodes Incorporated Diodes Incorporated Diodes Incorporated Diodes Incorporated
RoHS Status ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant
Description IC REG LINEAR 1.8V 600MA SOT223 IC REG LINEAR 2.5V 600MA SOT223 IC REG LINEAR 3.3V 600MA SOT223 IC REG LINEAR 4.8V 600MA SOT223
Series Diodes Incorporated Diodes Incorporated Diodes Incorporated Diodes Incorporated
Packaging Tape & Reel (TR) Tape & Reel (TR) Tape & Reel (TR)-->Cut Tape (CT) Tape & Reel (TR)
