APT15GP90BDQ1G
Manufacturer
Microchip TechnologyDescription
IGBT PT 900V 43A TO247
Datasheet
DatasheetPackage
TO-247-3
In Stock
46,017 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APT15GP90BDQ1G
APT15GP90BDQ1G
lmages are for reference only.Payment Methods
Delivery Services
IGBT PT 900 V 43 A 250 W Through Hole TO-247 [B]
Quick Inquiry
APT15GP90BDQ1G
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microchip Technology |
| Series | POWER MOS 7® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Voltage - Collector Emitter Breakdown (Max) | 900 V |
| Current - Collector (Ic) (Max) | 43 A |
| Current - Collector Pulsed (Icm) | 60 A |
| Vce(on) (Max) @ Vge, Ic | 3.9V @ 15V, 15A |
| Power - Max | 250 W |
| Switching Energy | 200µJ (off) |
| Input Type | Standard |
| Gate Charge | 60 nC |
| Td (on/off) @ 25°C | 9ns/33ns |
| Test Condition | 600V, 15A, 4.3Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | TO-247 [B] |
| Reverse Recovery Time (trr) | - |
| Base Product Number | APT15GP90 |
