Product CatalogPart Number
APT20GF120BRDG
Manufacturer
Microchip TechnologyDescription
IGBT NPT COMBI 1200V 20A TO-247
Datasheet
DatasheetPackage
TO-247-3
In Stock
70,822 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APT20GF120BRDG
APT20GF120BRDG
lmages are for reference only.Payment Methods
Delivery Services
IGBT NPT 1200 V 32 A 200 W Through Hole TO-247-3
Quick Inquiry
APT20GF120BRDG
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| IGBT Type | NPT |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 32 A |
| Current - Collector Pulsed (Icm) | 64 A |
| Vce(on) (Max) @ Vge, Ic | 3.2V @ 15V, 15A |
| Power - Max | 200 W |
| Switching Energy | - |
| Input Type | Standard |
| Gate Charge | 140 nC |
| Td (on/off) @ 25°C | 17ns/93ns |
| Test Condition | 792V, 20A, 10Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | TO-247-3 |
| Reverse Recovery Time (trr) | 85 ns |
| Base Product Number | APT20GF120 |
