APT40M70JVFR
lmages are for reference only.APT40M70JVFR
MOSFET N-CH 400V 53A ISOTOP
DatasheetSOT-227-4, miniBLOC
51,238 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 400 V 53A (Tc) 450W (Tc) Chassis Mount ISOTOP®
APT40M70JVFR
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microsemi Corporation |
| Series | POWER MOS V® |
| Packaging | Tube |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 400 V |
| Current - Continuous Drain (Id) @ 25°C | 53A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 70mOhm @ 26.5A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 2.5mA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 8890 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 450W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Supplier Device Package | ISOTOP® |
| Package / Case | SOT-227-4, miniBLOC |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 495 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | APT40M70JVR | APT40M35JVFR | APT40M35JVR | APT40M42JN |
| Manufacturer | Microchip Technology | Microsemi Corporation | Microchip Technology | Microsemi Corporation |
| RoHS Status | ||||
| Description | MOSFET N-CH 400V 53A SOT227 | MOSFET N-CH 400V 93A ISOTOP | MOSFET N-CH 400V 93A SOT227 | MOSFET N-CH 400V 86A ISOTOP |
| Series | POWER MOS V® | POWER MOS V® | POWER MOS V® | POWER MOS IV® |
| Packaging | Tube | Tube | Tube | Tray |
