APT5020BVRG
Manufacturer
Microchip TechnologyDescription
MOSFET N-CH 500V 26A TO247
Datasheet
DatasheetPackage
TO-247-3
In Stock
11,811 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APT5020BVRG
APT5020BVRG
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 500 V 26A (Tc) Through Hole TO-247 [B]
Quick Inquiry
APT5020BVRG
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microchip Technology |
| Series | POWER MOS V® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 500 V |
| Current - Continuous Drain (Id) @ 25°C | 26A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - |
| Rds On (Max) @ Id, Vgs | 200mOhm @ 500mA, 10V |
| Vgs(th) (Max) @ Id | 4V @ 1mA |
| Vgs (Max) | - |
| Input Capacitance (Ciss) (Max) @ Vds | 4440 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | - |
| Operating Temperature | - |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-247 [B] |
| Package / Case | TO-247-3 |
| Base Product Number | APT5020 |
| Gate Charge (Qg) (Max) @ Vgs | 225 nC @ 10 V |
| Grade | - |
| Qualification | - |
