APTGF180DH60G
Manufacturer
Microsemi CorporationDescription
IGBT MODULE 600V 220A 833W SP6
Datasheet
DatasheetPackage
SP6
In Stock
65,390 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APTGF180DH60G
APTGF180DH60G
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module NPT Asymmetrical Bridge 600 V 220 A 833 W Chassis Mount SP6
Quick Inquiry
APTGF180DH60G
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | NPT |
| Configuration | Asymmetrical Bridge |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 220 A |
| Power - Max | 833 W |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 180A |
| Current - Collector Cutoff (Max) | 300 µA |
| Input Capacitance (Cies) @ Vce | 8.6 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | - |
| Mounting Type | Chassis Mount |
| Package / Case | SP6 |
| Supplier Device Package | SP6 |
| Base Product Number | - |
