APTGT150H170G
Manufacturer
Microsemi CorporationDescription
IGBT MODULE 1700V 250A 890W SP6
Datasheet
DatasheetPackage
SP6
In Stock
56,780 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APTGT150H170G
APTGT150H170G
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Trench Field Stop Full Bridge Inverter 1700 V 250 A 890 W Chassis Mount SP6
Quick Inquiry
APTGT150H170G
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Configuration | Full Bridge Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
| Current - Collector (Ic) (Max) | 250 A |
| Power - Max | 890 W |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 150A |
| Current - Collector Cutoff (Max) | 350 µA |
| Input Capacitance (Cies) @ Vce | 13.5 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SP6 |
| Supplier Device Package | SP6 |
| Base Product Number | APTGT150 |
Parts with Similar Specifications
| Product Attribute | |
|
 |
|
| Part Number | APTGT150H120G | APTGT150A120G | APTGT150A120T3AG | APTGT150A120TG |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IGBT MODULE 1200V 220A 690W SP6 | IGBT MODULE 1200V 220A 690W SP6 | IGBT MODULE 1200V 220A 833W SP3 | IGBT MODULE 1200V 220A 690W SP4 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
