AS1331-BTDT-33
lmages are for reference only.AS1331-BTDT-33
IC REG BCK BST 3.3V 450MA 10TDFN
Datasheet10-WFDFN Exposed Pad
18,872 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Buck-Boost Switching Regulator IC Positive Fixed 3.3V 1 Output 450mA (Switch) 10-WFDFN Exposed Pad
AS1331-BTDT-33
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | ams-OSRAM USA INC. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Buck-Boost |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 1.8V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Current - Output | 450mA (Switch) |
| Frequency - Switching | - |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 10-WFDFN Exposed Pad |
| Supplier Device Package | 10-TDFN (3x3) |
| Base Product Number | AS1331 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AS1331-BTDT-30 | AS1331-BTDT-33-6K | AS1331-BTDT | AS1331-BTDT-25 |
| Manufacturer | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| RoHS Status | RoHS Compliant | |||
| Description | IC REG BUCK BST 3V 450MA 10TDFN | IC REG BCK BST 3.3V 450MA 10TDFN | IC REG BUCK BST ADJ 450MA 10TDFN | IC REG BCK BST 2.5V 450MA 10TDFN |
| Series | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. | ams-OSRAM USA INC. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
