ASDXAVX001PGAA5
lmages are for reference only.ASDXAVX001PGAA5
SENSOR 1PSIG 0.09" 4.5V
Datasheet8-DIP Module
46,879 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 1PSI (6.89kPa) Vented Gauge Male - 0.09" (2.31mm) Tube 0.5 V ~ 4.5 V 8-DIP Module
ASDXAVX001PGAA5
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Honeywell Sensing and Productivity Solutions |
| Series | ASDX |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Base Product Number | ASDXAVX001 |
| Applications | Board Mount |
| Pressure Type | Vented Gauge |
| Operating Pressure | 1PSI (6.89kPa) |
| Output Type | Analog Voltage |
| Output | 0.5 V ~ 4.5 V |
| Accuracy | ±2% |
| Voltage - Supply | 4.75V ~ 5.25V |
| Port Size | Male - 0.09" (2.31mm) Tube |
| Port Style | Barbless |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 2PSI (13.79kPa) |
| Operating Temperature | -20°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP Module |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | ASDXAVX001PG7A5 | ASDXAVX001PG7A5 | ASDXAVX001PGAA5 | ASDXAVX005PG2A5 |
| Manufacturer | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | SENSOR 1PSIG 0.09" 12BIT | SENSOR 1PSIG 0.09" 12BIT | SENSOR 1PSIG 0.09" 4.5V | SENSOR 5PSIG 0.09" 12BIT |
| Series | ASDX | ASDX | ASDX | ASDX |
| Packaging | Bulk | Bulk | Bulk | Bulk |
