ASL5015SHV/0Y
lmages are for reference only.ASL5015SHV/0Y
IC LED DRV CTRL PWM 1.5A 48HLQFP
Datasheet48-LQFP Exposed Pad
72,760 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 12 Output DC DC Controller Switched Capacitor (Charge Pump) PWM Dimming 1.5A 48-HLQFP (7x7)
ASL5015SHV/0Y
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | NXP USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Controller |
| Topology | Switched Capacitor (Charge Pump) |
| Internal Switch(s) | Yes |
| Number of Outputs | 12 |
| Voltage - Supply (Min) | 4.5V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 1.5A |
| Frequency | 200MHz |
| Dimming | PWM |
| Applications | - |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 48-LQFP Exposed Pad |
| Supplier Device Package | 48-HLQFP (7x7) |
| Base Product Number | ASL5015 |
| Grade | Automotive |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | ASL5015FHNZ | ASL5015FHV/0Y | ASL5015SHNZ | ASL1500SHNY |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC LED DRV CTRL PWM 1.5A 36HVQFN | IC LED DRV CTRL PWM 1.5A 48HLQFP | IC LED DRV CTRL PWM 1.5A 36HVQFN | IC LED DRIVER CTRLR 32HVQFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
