AT13-18PC-BM01GN
Manufacturer
Amphenol Sine Systems CorpDescription
18 POSITION, RIGHT ANGLE FLANGE
Datasheet
DatasheetPackage
-
In Stock
78,125 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AT13-18PC-BM01GN
AT13-18PC-BM01GN
lmages are for reference only.Payment Methods
Delivery Services
Connector Header Through Hole, Right Angle 18 position 0.185" (4.70mm)
Quick Inquiry
AT13-18PC-BM01GN
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Male Pins |
| Manufacturer | Amphenol Sine Systems Corp |
| Series | BoardLock™ AT |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle |
| Contact Type | Male Pin |
| Pitch - Mating | 0.185" (4.70mm) |
| Number of Positions | 18 |
| Number of Rows | 3 |
| Row Spacing - Mating | 0.193" (4.90mm) |
| Number of Positions Loaded | All |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall |
| Mounting Type | Through Hole, Right Angle |
| Termination | Solder |
| Fastening Type | Latch Holder |
| Contact Length - Mating | - |
| Contact Length - Post | 0.114" (2.90mm) |
| Overall Contact Length | - |
| Insulation Height | 1.390" (35.30mm) |
| Contact Shape | Circular |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | - |
| Contact Finish - Post | - |
| Contact Material | Copper Alloy |
| Insulation Material | Thermoplastic |
| Features | Board Guide, Mounting Flange |
| Operating Temperature | -55°C ~ 125°C |
| Ingress Protection | IP68/IP69K - Dust Tight, Water Resistant, Waterproof |
| Material Flammability Rating | - |
| Insulation Color | Green |
| Current Rating (Amps) | 13A |
| Voltage Rating | 250V |
| Mated Stacking Heights | - |
| Contact Finish Thickness - Post | - |
| Applications | Automotive, Industrial |
| Base Product Number | AT13 |
