ATA5743P3-TGQY 19
lmages are for reference only.ATA5743P3-TGQY 19
RF RX ASK/FSK 300-450MHZ 20SOIC
Datasheet20-SOIC (0.295", 7.50mm Width)
10,727 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
- RF Receiver ASK, FSK 300MHz ~ 450MHz -110dBm 10kBaud PCB, Surface Mount 20-SOIC
ATA5743P3-TGQY 19
| Category | RF and Wireless - RF Receivers - |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Frequency | 300MHz ~ 450MHz |
| Sensitivity | -110dBm |
| Data Rate (Max) | 10kBaud |
| Modulation or Protocol | ASK, FSK |
| Applications | RKE, Telemetering, Security Technology |
| Current - Receiving | 7.5mA |
| Data Interface | PCB, Surface Mount |
| Memory Size | - |
| Antenna Connector | PCB, Surface Mount |
| Features | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | ATA5743P3-TGQY 19 | ATA5743P3-TGSY | ATA5743P3-TGSY | ATA5743P3-TKQY 19 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RF RX ASK/FSK 300-450MHZ 20SOIC | RF RX ASK/FSK 300-450MHZ 20SOIC | RF RX ASK/FSK 300-450MHZ 20SOIC | RF RX ASK/FSK 300-450MHZ 20SSO |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tube | Tube | Tape & Reel (TR) |
