ATA5795-PNQW
lmages are for reference only.ATA5795-PNQW
RF TX IC ASK 125KHZ/315MHZ 32QFN
Datasheet32-VFQFN Exposed Pad
12,891 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Transmitter ASK, FSK 125kHz, 315MHz, 433MHz 12.5dBm 40kbps PCB, Surface Mount Antenna 32-VFQFN Exposed Pad
ATA5795-PNQW
| Category | RF and Wireless - RF Transmitters - |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Frequency | 125kHz, 315MHz, 433MHz |
| Applications | RKE |
| Modulation or Protocol | ASK, FSK |
| Data Rate (Max) | 40kbps |
| Power - Output | 12.5dBm |
| Current - Transmitting | 7.3mA |
| Data Interface | PCB, Surface Mount |
| Antenna Connector | PCB, Surface Mount |
| Memory Size | 8kB Flash, 512B SRAM |
| Features | - |
| Voltage - Supply | 1.9V ~ 3.6V |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Surface Mount |
| Package / Case | 32-VFQFN Exposed Pad |
| Supplier Device Package | 32-QFN (5x5) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ATA5791-WDQW-1 | ATA5795C-PNQW | ATA5795C-PNQW 18 | ATA8520-GHQW |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC TX UHF ASK/FSK QFN | RF TX IC ISM 315-433MHZ 32VFQFN | RF TX IC ISM 315-433MHZ 32WFQFN | RF TRANSMITTER 868MHZ 32VFQFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
