ATF1504AS-7JC68
lmages are for reference only.ATF1504AS-7JC68
IC CPLD 64MC 7.5NS 68PLCC
Datasheet68-LCC (J-Lead)
80,358 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ATF1504AS-7JC68
| Category | Integrated Circuits (ICs) - Embedded - CPLDs Complex Programmable Logic Devices |
| Manufacturer | Microchip Technology |
| Series | ATF15xx |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Programmable Type | In System Programmable (min 10K program/erase cycles) |
| Delay Time tpd(1) Max | 7.5 ns |
| Voltage Supply - Internal | 4.75V ~ 5.25V |
| Number of Logic Elements/Blocks | - |
| Number of Macrocells | 64 |
| Number of Gates | - |
| Number of I/O | 48 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 68-LCC (J-Lead) |
| Supplier Device Package | 68-PLCC (24.23x24.23) |
| Base Product Number | ATF1504AS |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ATF1504AS-7JC44 | ATF1504AS-7JC84 | ATF1504AS-7JX44 | ATF1504AS-10AC100 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC CPLD 64MC 7.5NS 44PLCC | IC CPLD 64MC 7.5NS 84PLCC | IC CPLD 64MC 7.5NS 44PLCC | IC CPLD 64MC 10NS 100TQFP |
| Series | ATF15xx | ATF15xx | ATF15xx | ATF15xx |
| Packaging | Tube | Tube | Tube | Tray |
