ATS137-PG-A-B
lmages are for reference only.ATS137-PG-A-B
MAGNETIC SWITCH UNIPOLAR 3SIP
Datasheet3-SIP, Formed Leads
55,182 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Digital Switch Unipolar Switch Open Collector Hall Effect 3-SIP
ATS137-PG-A-B
| Category | Sensors, Transducers - Magnetic Sensors - Switches Solid State |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Function | Unipolar Switch |
| Technology | Hall Effect |
| Polarization | South Pole |
| Sensing Range | 13mT Trip, 1mT Release |
| Test Condition | 25°C |
| Voltage - Supply | 3.5V ~ 20V |
| Current - Supply (Max) | 10mA |
| Current - Output (Max) | 25mA |
| Output Type | Open Collector |
| Features | Temperature Compensated |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 3-SIP |
| Package / Case | 3-SIP, Formed Leads |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ATS137-PG-A-A | ATS137-PG-B-A | ATS137-PG-B-B | ATS137-PL-A-B |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MAGNETIC SWITCH UNIPOLAR 3SIP | MAGNETIC SWITCH UNIPOLAR 3SIP | MAGNETIC SWITCH UNIPOLAR 3SIP | MAGNETIC SWITCH UNIPOLAR 3SIP |
| Series | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| Packaging | Tape & Box (TB) | Bulk | Bulk | Cut Tape (CT) |
