AWSCR-5.00CRLB-C15-T3
lmages are for reference only.AWSCR-5.00CRLB-C15-T3
CERAMIC RES 5.0000MHZ 15PF SMD
Datasheet3-SMD, Non-Standard
81,243 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
5 MHz Ceramic Resonator Built in Capacitor 15 pF ±0.4% 40 Ohms -40°C ~ 125°C Surface Mount
AWSCR-5.00CRLB-C15-T3
| Category | Crystals, Oscillators, Resonators - Resonators - |
| Manufacturer | Abracon LLC |
| Series | AWSCR-CRLB |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Ceramic |
| Frequency | 5 MHz |
| Frequency Stability | ±0.4% |
| Frequency Tolerance | ±0.5% |
| Features | Built in Capacitor |
| Capacitance | 15 pF |
| Impedance | 40 Ohms |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 3-SMD, Non-Standard |
| Size / Dimension | 0.177" L x 0.079" W (4.50mm x 2.00mm) |
| Height | 0.039" (1.00mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AWSCR-5.00CPLA-C30-T4 | AWSCR-5.00CPLB-C30-T4 | AWSCR-5.00CRLA-C15-T3 | AWSCR-5.00CRLA-C39-T3 |
| Manufacturer | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CERAMIC RES 5.0000MHZ 30PF SMD | CERAMIC RES 5.0000MHZ 30PF SMD | CERAMIC RES 5.0000MHZ 15PF SMD | CERAMIC RES 5.0000MHZ 39PF SMD |
| Series | AWSCR-CPLA | AWSCR-CPLB | AWSCR-CRLA | AWSCR-CRLA |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
