AZ9422-1CE-48DF
Manufacturer
American ZettlerDescription
RELAY GEN PURPOSE SPDT 20A 48V
Datasheet
DatasheetPackage
-
In Stock
44,279 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AZ9422-1CE-48DF
AZ9422-1CE-48DF
lmages are for reference only.Payment Methods
Delivery Services
General Purpose Relay SPDT (1 Form C) 48VDC Coil Through Hole
Quick Inquiry
AZ9422-1CE-48DF
Specifications
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | American Zettler |
| Series | AZ9422 |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 48VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 20 A |
| Switching Voltage | 277VAC, 30VDC - Max |
| Load - Max Switching | 4700VA, 480W |
| Coil Current | 7.5 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Flux Protection |
| Coil Insulation | Class F |
| Must Operate Voltage | 36 VDC |
| Must Release Voltage | 4.8 VDC |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Approval Agency | CQC, CUR, TUV, UL |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 6.4 kOhms |
| Base Product Number | AZ9422-1C |
