Product CatalogPart Number
AZ9801-1A-24DH
Manufacturer
American ZettlerDescription
RELAY AUTOMOTIVE SPST 70A 24V
Datasheet
DatasheetPackage
-
In Stock
51,478 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AZ9801-1A-24DH
AZ9801-1A-24DH
lmages are for reference only.Payment Methods
Delivery Services
Quick Inquiry
AZ9801-1A-24DH
Specifications
| Category | Relays - Automotive Relays - |
| Manufacturer | American Zettler |
| Series | AZ9801 |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Coil Type | Non Latching |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 70 A |
| Switching Voltage | 50VDC - Max |
| Must Operate Voltage | 14.4 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 10 ms |
| Release Time | 7 ms |
| Features | SUPER-ISO |
| Mounting Type | Socketable |
| Termination Style | Plug In, Quick Connect - Multiple Sizes |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Coil Power | 2W |
| Coil Resistance | 288 Ohms |
| Base Product Number | - |
| Coil Current | 83.3 mA |
