Product CatalogPart Number
B1509XT-1WR3
Manufacturer
Mornsun America, LLCDescription
DC DC CONVERTER 9V 1W
Datasheet
DatasheetPackage
8-SMD Module, 5 Leads
In Stock
22,448 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
B1509XT-1WR3
B1509XT-1WR3
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 9V 111mA 13.5V - 16.5V Input
Quick Inquiry
B1509XT-1WR3
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Mornsun America, LLC |
| Series | |
| Packaging | Tray |
| RoHS Status | |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 13.5V |
| Voltage - Input (Max) | 16.5V |
| Voltage - Output 1 | 9V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 111mA |
| Power (Watts) | 999 mW |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 105°C (With Derating) |
| Efficiency | 82% |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD Module, 5 Leads |
| Size / Dimension | 0.52" L x 0.33" W x 0.29" H (13.2mm x 8.5mm x 7.3mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | CB, CE, cURus, UKCA, UL |
| Standard Number | 62368-1 |
| Base Product Number | - |
| Voltage - Isolation | 1.5 kV |
Parts with Similar Specifications
| Product Attribute | |
 |
 |
 |
| Part Number | B1509XT-1WR3 | B1203D-1WR3 | B1203LS-1WR3 | B1203M-2WR3 |
| Manufacturer | Mornsun America, LLC | Mornsun America, LLC | Mornsun America, LLC | Mornsun America, LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | DC DC CONVERTER 9V 1W | DC DC CONVERTER 3.3V 1W | DC DC CONVERTER 3.3V 1W | DC DC CONVERTER 3.3V 2W |
| Series | ||||
| Packaging | B1509XT-1WR3 (1W) | B_D-1WR3 (1W) | B_LS-1WR3 (1W) | B1203M-2WR3 (2W) |
