B25632E1117K100
lmages are for reference only.B25632E1117K100
POWER ELECTRONIC CAPACITORS (PEC
DatasheetRadial, Can
68,231 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
110 µF Film Capacitor 1100V (1.1kV) Radial, Can
B25632E1117K100
| Category | Capacitors - Film Capacitors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | Ultra LSI |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 110 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 1100V (1.1kV) |
| Dielectric Material | - |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can |
| Size / Dimension | 3.327" Dia (84.50mm) |
| Height - Seated (Max) | 2.598" (66.00mm) |
| Termination | Threaded, Female |
| Lead Spacing | 1.772" (45.00mm) |
| Applications | DC Link, DC Filtering; Snubber |
| Ratings | - |
| Features | - |
| ESR (Equivalent Series Resistance) | 1.4 mOhms |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | B25632E1117K000 | B25632E1127K000 | B25631A0227K700 | B25631A107K900 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | POWER ELECTRONIC CAPACITORS (PEC | POWER ELECTRONIC CAPACITORS (PEC | CAP FILM 220UF 10% 700VDC RADIAL | CAP FILM 100UF 10% 900VDC RADIAL |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
