B32656S7684K563
lmages are for reference only.B32656S7684K563
CAP FILM 0.68UF 1.25KVDC SCREW
DatasheetRectangular Box
47,151 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
0.68 µF Film Capacitor 500V 1250V (1.25kV) Polypropylene (PP), Metallized Rectangular Box
B32656S7684K563
| Category | Capacitors - Film Capacitors - |
| Manufacturer | EPCOS - TDK Electronics |
| Series | B3265* - MKP General Purpose |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 0.68 µF |
| Tolerance | ±10% |
| Voltage Rating - AC | 500V |
| Voltage Rating - DC | 1250V (1.25kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | 1.654" L x 0.787" W (42.00mm x 20.00mm) |
| Height - Seated (Max) | 1.555" (39.50mm) |
| Termination | Screw Terminals |
| Lead Spacing | 2.244" (57.00mm) |
| Applications | Snubber |
| Ratings | AEC-Q200 |
| Features | Low ESL |
| ESR (Equivalent Series Resistance) | 6 mOhms |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | B32656S7684K561 | B32656S7684K562 | B32656S7684K564 | B32656S7684K565 |
| Manufacturer | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP FILM 0.68UF 1.25KVDC SCREW | CAP FILM 0.68UF 1.25KVDC SCREW | CAP FILM 0.68UF 1.25KVDC SCREW | CAP FILM 0.68UF 1.25KVDC SCREW |
| Series | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics | EPCOS - TDK Electronics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
